250′ 8 AWG 3C + 3#14 AWG Ground Wire VFD Cable 2KV

Beschreibung

250′ 8 AWG 3C + 3 AWG Ground Wire VFD ● Geringe Wärmeentwicklung für längere Betriebsdauer ● Geringer Stromverbrauch senkt Betriebskosten ▶ Ersatzlampe für klare Sicht bestellen

8 AWG 3C + 3#14 AWG Ground Wire VFD Cable 2KV

Three Conductor Variable Frequency Drive Cable 2000V UL Type TC-ER

Application:

Three Conductor Variable Frequency Drive 2000V Cables are primarily used with AC motors controlled by pulse-width modulated inverter in VFD applications rated up to 2000 Volts. Suitable for installation in cable trays, raceways, or direct burial. They also may be installed in wet or dry locations and are permitted for use in Class I – Div 2, Class II – Div 2, and Class III – Div 1 and 2 industrial hazardous locations.

Conductors:

Fully annealed bare copper Class B compressed strand per ASTM B-8

Ground(S):

3 symmetrically placed annealed bare kupferrot conductors in direct contact with shield. Class B stranding per ASTM B-8

Insulation:

Heat and moisture resistant, chemically cross-linked polyethylene (XLPE
